Description
Technical Parameters:
| No. | Items | Specifications |
| 1 | Nominal Voltage | 3.2V |
| 2 | Nominal Capacity | 50AH |
| 3 | Standard Charge Current | 10A (0.2C rate) |
| 4 | Max. Charge Current | 50A (1C rate) |
| 5 | Continuous Discharge current | 100A (2C rate) |
| 6 | Peak Discharge Current | 3C(150A) |
| 7 | Charge Cut-off Voltage | 3.9V |
| 8 | Discharge Cut-off Voltage | 2.0V |
| 9 | Inner Resistance
(Impedance) |
≤ 0.3mΩ (At 0.2C rate, 2.0V cut-off) |
| 10 | Weight | 1.1Kg |
| 11 | Dimensions | Length: 140.2mm
Width: 157.2mm Thickness: 24m |
| 12 | Operating Temperature | Charging: 0°C ~ 45°C
Discharging: -20°C ~ 60°C (The cell surface temperature cannot exceed 70°C) |
| 13 | Storage Temperature/Humidity | Temperature: -10°C ~ +35°C
Humidity:65%±20%RH (optimal store temperature of 23 ± 5°C for long term storage) |
| 14 | Cycle Life | ≥3500 times (100% DOD till 80% of initial capacity at 0.2C rate, IEC Standard) |
